CARE

Care and maintenance

An annual service by a trained garage door technician is
required to maintain the safety and smooth operation of
your garage door.

scroll down

Garage door springs, cables, brackets, and other hardware attached to the springs are under very high tension and, if handled improperly, can cause serious injury. Only a qualified professional or a mechanically experienced person should adjust them, but only by carefully following the manufacturer’s instructions. The torsion springs (the springs above the door) should only be adjusted by a professional. Do not attempt to repair or adjust torsion springs yourself. A restraining cable or safety clips should be installed on the extension spring (the spring along the side of the door) to help contain the spring if it breaks.

WARNING! Springs are under high tension. Only qualified persons should adjust them. Take a few minutes to inspect and test your complete garage door system. Make monthly inspection and testing a part of your regular routine.

Stand inside the garage with the garage door in the closed position. Have a good look at the garage door springs, rollers, and mounting hardware, such as the hinges for signs of wear and tear or damage. Also look at the cables for signs of fraying. Make sure that the mounting hardware is adequately fastened, nothing should be loose. If something doesn’t look quite right – or doesn’t sound quite right – it could be the symptom of a more serious issue. We suggest you have the garage door checked by one of our service technicians.

If your door is installed with an automatic operator, close the door and disengage the operator. Once you are able to lift the door manually… Lift the door. It should lift smoothly with little resistance and should remain fully open. If it is difficult to open or does not remain fully open, the door may be off balance and should be serviced.

If your door is equipped with an automatic operator, have the door in the fully open position; push your remote or wall button to close the door. As the door is closing, place the palm of your hand/s at the bottom of the door and apply some resistance. If the door does not easily reverse and continues to close, pull your hands away immediately. The closing force is excessive and could do some harm. The door will need to be serviced if this scenario occurs.

Apply a small amount of spray lubricant such as Q20, or any other light oil lubricant to the door hinges, rollers, tracks, springs, cables and all other working parts that are subjected to wear and tear. It is advisable to lubricate the chain inside the shaft of the automatic operator. ?(NB!!! DO NOT USE GREASE AS A FORM OF LUBRICANT!)

If your garage door motor has a battery backup in case of a power failure, it is advisable to check on a weekly basis that the battery has sufficient power to avoid the inconvenience of being shut out of your garage. This is because the battery has a limited life span of approximately one year. In order to maximize the life span of the battery, we advise that it be run flat every two weeks. This is done by switching off the power to the motor and operating the door off the battery until it no longer operates. Then switch the power back on – this will re charge the battery.

Our springs are designed to the industry standard of 10 000 cycles (approx. 5 years). It is advisable to have the springs replaced at 5 year intervals to avoid the inconvenience of them breaking, which will result in you not being able to operate your door. Long life springs of 20 000 cycles are available on request at an additional cost.

Sectional Garage Doors are the most popular and practical choice in terms of style, safety, security and ease of use and the most frequently specified door mechanism by the professional sector.

Sectional Garage Doors are usually constructed of five to eight panels and slide up and overhead.

Sectional Garage Doors do not require any space outside the garage to open. A vehicle may park very close to the garage before opening the door.

Each panel of a sectional door has its own connection to the door track. This increases reliability and robustness.

Tracks and hinges are hot dipped galvanised steel for maximum corrosion protection, with robust nylon wheels containing ball bearings for a smoother, quieter, and more durable operation.

Sectional Garage Doors are highly recommended for adverse weather conditions.

The door’s wedging action excludes dust, wind and weather seals on the bottom are standard.

Can be used where headroom is limited, i.e. less than 150mm, using double tracks or special ‘low headroom’ tracks.

Available in torsion hardware sets.

Supplied with a slide bolt for locking purposes on non-automated doors.
A chrome-plated centre lock with dual catches and cables is available as an optional extra for garages with no internal door.

Suitable for single or double doors. Can be custom-made to suit openings.
